HW-BB Forging bolted bonnet Trunnion Mounted Ball valve
Design&Manufacturing:API6D;API608
End to end Dimension:API6D;ASME B16.10
End connection: ASM/ANSI B16.5&B16.47a&B16.25;JIS;EN;DIN
Test & Inspection: API6D;API598
Pressure rating: class150lb/PN16~25, class300lb/PN40, class600lb/PN80-100, class900lb/PN160, class1500lb/PN250, class2500lb/PN420
Sizes: 2" - 56" / DN 50 – DN 1400
Aplications: oil, crude oil, natural gas etc.

Overview:
HW-BB type ball valve is on /off control valve which uses trunnion mounted ball, forging body, bolted body design. The forging body ensures the quality, strength and rigidity of the valve body. The design and selection of bolted body is carefully and accurately calculated in order to ensure its rigidity, so it is safe to use this series of ball valves. The design of seat seal uses unique two-level soft seal and metal to metal seal to form triple sealing to ensure seal reliability with small open/close torque and easy operation. This type of valve is widely used in the nature gas and oil pipeline, the industries of petrochemical, medicine, city constructions, etc.
Features of Product Design
Full bore or reduced bore design
Fire-safe design in compliance with API607/API6FA
All forged metal parts including body and ball, etc.
Anti-static design in compliance with BS5351
Cavity self-relief under overpressure
Floating seats, bi-directional sealing, two-level soft seal rings and metal
Seat and stem are with emergency sealant injector and structure to metal seal form triple sealing
Flexible open/close, easy operation, long life cycle
Double block and bleed structure(DBB) free of maintenance
Material

Body Ball Seat ring Stem
CS(A105, A350 LF2, A694) CS+ENP SS DSS(A182 F51) CS+ENP SS DSS(A182 F51) CS/AS+ENP SS DSS(A182 F51)
SS&DSS (A182 F6a, F304, F316 F316L,17-4PH,F51) CS+ENP SS DSS(A182 F51) CS+ENP SS DSS(A182 F51) CS/AS+ENP SS DSS(A182 F51)

Pressure rating: class150lb/PN16~25, class300lb/PN40, class600lb/PN80-100, class900lb/PN160, class1500lb/PN250, class2500lb/PN420
Sizes: 2" - 56" / DN 50 – DN 1400
Aplication: oil, crude oil, natural gas etc.
Temperature:-196-256℃
Operation: Lever, Gearbox, Electric, Pneumatic, Hydraulic, Pneumatic-hydraulic, Electric-hydraulic.
